Description
Used Replacement for Bitmain APW12 Power Supply for 19 Series miners
Works with S19 Pro, and S19 Miners
Specifications:
OUT1
DC voltage:12V-15V
Rated current:300A
Ripple and noise:<1%
Source regulation:<1%
Load regulation:<1%
Startup, rise time:<2S
Power-down hold time:≥10mS
OUT2
DC voltage:12.3V
Rated current :15A
Ripple and noise:<1%
Voltage accuracy:12.2V—12.4V
Source regulation rate:<1%
Load regulation rate:<1%
Start-up, rise time:<2S
power down Holding time:≥10mS
Input
voltage range:180-300VAC
Frequency range:50-60Hz
Power factor:≥0.99 (full load)
Leakage current:<1.5mA (50Hz)
Protection
Input undervoltage protection value:80-89VAC
Output short circuit:Yes
Over temperature protection:Yes
Output overcurrent protection value:291A-350A (different voltage, different protection value)
Environment
Working temperature:-20-45℃
Working humidity:20%-90%RH (no condensation)
Altitude:less than 2000m
Structure
size:254.6mm*251.6mm*63mm
Net weight 3.6Kg
Cooling method: forced air cooling
Noise:45dBA
Name: Power Supply
