Description
BITMAIN APW121215a v1.32
EXCELLENT LIKE NEW CONDITION
TESTED 100% WORKING
| DC Voltage | 12V-15V | |
| Rated Current(220 V input) | 233A | |
| Ripple & Noise | <1% | |
| Line Regulation | <1% | |
| Load Regulation | <1% | |
| Setup Time | <2S | |
| Short Circuit Protection | >10mS | |
| OUT2 | DC Voltage | 12.3V |
| Rated Current(220 V input) | 15A | |
| Ripple & Noise | <1% | |
| Voltage Accuracy | 12.2V—12.4V | |
| Line Regulation | <1% | |
| Load Regulation | <1% | |
| Setup Time | <2S | |
| Short Circuit Protection | >10mS | |
| Input | Voltage Range | 200-240V AC |
| Frequency Range | 47-63Hz | |
| Power Factor | >0.99(full load) | |
| Leakage Current | <1.5mA（220V 50Hz） | |
| Protection | Low-voltage Input | 80-89V AC |
| Output Short Circuit | Yes | |
| Overheat Protection | Yes | |
| Over-current Output | 291A-350A （protection value varies under different voltage） |
|
| Environment | Operating Temperature | -20-45℃ |
| Operating Humidity | 20%-90%RH（non-condensing） | |
| Altitude | < 2000m | |
| Structure | Dimensions | 254.6mm*251.6mm*63mm |
| Net Weight | 3.6KG | |
| Cooling System | forced‐air cooling | |
| Noise | 45dBA |
